Product Information
MFT Plateanker
Elforsinket for enkel gipsplate
- Product number:
- 241017
- GTIN-no:
- 7034352410173
- Product name:
- BOARD ANCHOR ZP 6S M5X58 E A4
- Dimensions:
- Dimensions (D x L):
- M6 x 58 mm
- Dimensions (D x max attachment/L):
- Total lenght:
- Length:
- Max attachment:
- Screw dimensions:
- M6
- For screw dimension:
- Screw length:
- 58 mm
- Body diametre:
- Thread dimensions:
- Min screw length:
- Anchor length:
- 52 mm
- Drill dimension:
- Ø11 mm
- Drilling depth:
- Groove type:
- Kombi (Spor / PH)
- Screw head:
- Pan
- Collar:
- 16,0 mm
- Sleeve thickness:
- 9,0 mm
- Internal loop:
- Max extraction (wood):
- Max extraction (plaster fixing):
- Max extraction ceiling (plaster 1 x 13mm):
- 0,3 kN
- Max extraction ceiling (plaster 2 x 13mm):
- Max extraction (Leca):
- Max extraction (concrete):
- Max extraction (concrete B20 / 25):
- Max extraction (brick/tile):
- Max extraction (hole brick):
- Max shear (wood):
- Max shear (plaster fixing):
- Max cut wall (plaster 1 x 13 mm):
- 0,4 kN
- Max cut wall (plaster 2 x 13 mm):
- Max shear (concrete):
- Max cut (concrete):
- Max shear (brick/tiles):
- For plate thickness:
- 3 - 16 mm
- Colour:
- Material:
- Stål
- Coating:
- Elektrolytisk forsinket
- Load:
- Lett / middels
- Pcs / Pkt:
- 4
Features
MFT Plateanker, elforsinket for enkel gipsplate. Kraftig spesialfeste for div feste i gips. Stort bruksområde. Tang anbefales for rask montering. MFT Plateanker er markedets kraftigste festemiddel for gips med høyeste uttrekksverdier.
More information
MFT Plateanker elforsinket. Leveres i småpakk 4 st/pk
MFT Plateanker elforsinket brukes til div. tyngre oppheng opptil 30 kg i enkel gipsplate/plater i tykkelse 3-16mm. For innendørs bruk. Må formonteres. Belastning - Lett/middels
| Dimensjon | Bordimensjon | Krave D |
|---|---|---|
| M4 | Ø8 | 13,5 |
| M6 | Ø11 | 16,0 |
| M8 | Ø13 | 17,5 |
